Description SENKO SI-100D is an Intrinsically Safe Gas Leak Detector with ATEX Zone 1 certification for usage in potentially explosive atmospheres. With IECEx certification as a guarantee. There are two parts to this flammable gas detector, the SI-100D SET. For gas leak detection, this is what you’d use. In terms of price point, the SI-100D SET is a good entry-level device. Economic fixed gas detector, LNG/LPG (methane/propane) measurement range, diffusion type, wall mount, -20oC to 50oC working temperature, aluminum material, 0.6 kg in weight, simple construction, and affordable pricing are some of the good characteristics included. Features: ATEX Zone 1 Economic fixed type gas detector (Combustible, 0~100%LEL) Explosion proof structure Long-distance communication with 4~20mA analog output Convenient installation Simple structure, reasonable price aluminum material -20ºC~ 50ºC temperature Applications: Steelworks Sewage treatment plant Petrochemical plant Shipbuilding yard LPG tank facilities LNG gas plant Specifications ModelSD-100D Measuring rangeLNG/LPG(methane/propane) Measuring typeDiffusion type Measuring methodCatalytic Measuring range0~100%LEL Sensor life time> 2 years Response time<10sec/90%scale Accuracy±3%/Full scale Output signal4-20mA DC Cable/DistanceCVVSB 1.5sq or AWG20 × 3wire (Power Signal) / 2,500m max Conduit connectionNPT 1/2" Mounting typeWall mount Operating temperature-20ºC ~ 50ºC Operating humidity0%~95% RH(Non-condensing) Operating power24V DC /- 20%, <90mAh MaterialAluminium Dimensions93(W) × 106(H) × 89(D)mm 0.6kg ApprovalEx d II B T4/14-KB2BO-0422 (KTL) Certifications: ATEX Certificate KCS Certificate – Korean Resources: SENKO Catalog Data Sheet – Korean
