Description 3268 EX Explosion Proof Scissor Lift The 3268 EX Explosion Proof Scissor Lift is engineered for safe and reliable access in classified hazardous environments. Certified for Class 1, Division 1, Group D, it is designed for industries where flammable gases or vapors are present, such as oil & gas, chemical, and manufacturing sectors. With a maximum working height of 38 ft and a 700 lb platform capacity, this lift provides the reach and stability needed for elevated tasks. It features a spacious 68” x 84” platform with a 5 ft extendable deck for additional working space. Safety is enhanced with proportional drive controls, a battery condition indicator, full-height swing gates, and movement alarms — making it a dependable solution for hazardous-area operations. Key Features: ✅ Explosion Proof – Class 1, Division 1, Group D ✅ UL 583 Type EX compliant ✅ ANSI A92.20 & CSA B354.6 compliant ✅ 38 ft working height, 32 ft platform height ✅ 42” x 84” spacious platform with 4 ft extension ✅ 700 lb platform capacity (250 lb deck extension) ✅ Proportional drive controls for precision ✅ Battery condition indicator with 250 Amp-hour batteries ✅ Movement alarm and full-height swing gate for safety ✅ Optional explosion-proof work light, padded rails, and airline to platform �� Package Options: �� Standard: 5 ft manual deck extension, battery-powered �� Optional: Padded aircraft rails for added protection �� Optional: Explosion-proof work light for better visibility �� Optional: Additional 1/2” airline to platform for pneumatic tools 3268 EX Explosion-Proof Scissor Lift Technical Specifications: FeatureDetails Working Height38 ft (11.6 m) Platform Height32 ft (9.8 m) Platform Size (Inside)68 x 84 in Platform Capacity700 lbs (318 kg) Deck Extension4 ft (manual) Deck Extension Capacity250 lbs Overall Width47 in (1.2 m) Overall Length108 in (2.75 m) Stowed Height88 in (2.2 m) Ground Clearance (Stowed)3.5 in (8.9 cm) Ground Clearance (Raised)0.75 in (1.9 cm) Wheelbase69 in (1.8 m) Inside Turning Radius47.5 in (1.2 m) Outside Turning Radius93.5 in (2.4 m) Drive Speed (Stowed)1 mph (1.6 km/h) Drive Speed (Raised)0.5 mph (0.8 km/h) Power4 x 6V 250 Amp-hr batteries Charger20 Amp Automatic SCR Explosion Proof CertificationClass I, Division 1, Group D ComplianceUL 583 Type EX, ANSI A92.20, CSA B354.6 Certifications & Compliance: ��Class I, Division 1, Group D – Explosion Proof Compliance �� UL 583 Type EX – Electrical safety standard for explosion-proof equipment �� ANSI A92.20 & CSA B354.6 – Aerial lift safety standards �� ISO 9001:2015 – Certified quality manufacturing �� Download Datasheet Applications of 3247EX Explosion Proof Scissor Lift: �� Oil & Gas �� Chemical Plants �� Mining �� Labs �� Manufacturing What’s in the Box? �� 1x 3247EX Explosion Proof Scissor Lift �� 1x Battery Pack (4x 6V 250 Amp-hr) �� 1x Charger (20 Amp Automatic SCR) �� 1x Documentation Kit Ordering & Shipping Details �� Lead Time: 12 – 14 weeks �� Shipping Terms: Worldwide / Expedited Options �� Payment Options: Credit Card, PayPal, Net 30 Terms FAQs: Is the 3268 EX suitable for Zone 1 environments? This model is certified for Class 1, Division 1, Group D. Contact us for Zone certification details. Can the deck extension be powered? The deck extension is manual by default; pneumatic options are available for some configurations. What type of charger is included? A 20 Amp Automatic SCR charger is included.
