Description RamFan XP500 – 18″ Explosion Proof Fan Motor In order to ensure a safe working environment, the ATEX Zone 1 certified explosion proof fan motor of the RamFan XP500 – 18″ was used to build the fan. In a single package, convenience and performance are offered. This allows the fire truck to power the XP500 while it is conducting PPV at the building’s front door. The fan may be hooked into the house’s electrical system with a simple flick of a switch. Features: ATEX Zone 1 Electric Blower with Explosion-Proof Motor 2nd Generation PowerStream Air Straightener Full-width retractable handle for upright, push/pull operation and compact storage when down 0-20° tilt adjustment for precise positioning WIDE-Trac semi-pneumatic urethane tires easily roll over mud or rough terrain Optional Integrated Mister 1″ (25mm) powder-coated steel frame Made in California, USA Specifications: ModelXP500 PartEB90600X Weight72 lbs / 33 kg Impeller5-Blade Dimensions / (h/w/d)23.5 x 21 x 18.5 in / 60 x 53 x 47 cm Motor1.5 Hp / 1.1 kW Amps (Start/Run)80A / 15A Noise97 dB@3' (1 m) / 95 dB@10' (3 m) Electric115V, 1ø, 50/60Hz ApprovalsCE Airflow Airflow through11,540 cfm Single Door19,618 m³/hr Resources: Product Sheet User and Safety Guide
